LUGN3_MDVEPV_1623

Technical data

Main features and materials
• Body: Ductile Iron
• Disc: Ductile Iron
• Pin: Stainless Steel
• Stem: Stainless Steel
• Seat: Vulcanized EPDM
• Operation: Gearbox in Ductile Iron
• Coating: RAL 5015 (thickness 250 micron)
• USP: Dead-end/center service
• Standard: Standard acc. to BS EN 593
• Dimensions: Face-to-Face acc. to BS EN 558 (series 20)
• Type: Drilling: PN 16
Shaft: SS AISI 431
Thread: Metric
• Tests: Inspection test acc. to BS EN 12266-1

Field of applications
• Temperature range: -15 to 120 °C
• Max. working pressure: 16 bar
